Single-Phase Pole-Mounted Transformer is crafted with premium-grade copper windings and high-quality insulating oil. These units can be customized to meet the specific requirements of power utilities in most countries. EUE Power prioritizes customer satisfaction.

Cylindrical sealed structure: Each unit of the transformer is equipped with ANSI-compliant grounding devices, lifting hooks, and support lugs. It includes one or two high-voltage bushings on the cover, low-voltage bushings on the tank wall, as well as eyebolts and connection terminals. Please note that the tap-changer must be adjusted according to the instructions only after the power is turned off.

• Compliant with IEEE C57, ANSI C57, IEC60076, and various national standards.

• Core and Windings: CRGO (Cold Rolled Grain Oriented Silicon Steel) or amorphous metal core; copper or aluminum windings

• Automatic pressure relief valve.

• PCB-free insulation oil.

• Anti-corrosion electrostatic powder coating.

• Recessed base design.

• 50/60Hz frequency support.

• Weatherproof bushing mounting (HV/LV).

• Installation: Suitable for both indoor and outdoor use.

• Altitude: ≤ 2000m above sea level.

• Ambient Temperature: Maximum 40℃; Minimum -25℃.

• Relative Humidity: Monthly average 95%; Daily average 90%.

• Environment: Free from corrosive or flammable gases and vapors.

• Vibration: Free from frequent violent vibrations.

EUE Power Distribution Transformers:

Engineered for safety and sustainability, our transformers feature flame-retardant, low-noise designs that fully comply with UL and IEEE standards. They are ideal for critical environments such as hospitals, data centers, and urban infrastructure. As a premier Chinese manufacturer of 10kV, 20kV, and 35kV transformers, we guarantee rigorous quality control, fast lead times, and tailored configurations. Secure your eco-conscious power solution today!
